GV500CNA - 4G LTE Cat 1 Compact OBD Tracker
Description:
The GV500CNA is a small LTE CAT 1 OBD tracker equipped with features such as driver behavior monitoring, crash detection, mileage recording, and BLE connectivity, making it an ideal choice for insurance applications and connected car services.
**Data Cable Sold Separately: GV500M Download Cable
GV500CNA Queclink Flyer - Click to Open PDF
Features:
- LTE Cat 1
- Mini Size
- Plug and Play
- BLE 5.1
- Accelerometer Self-calibration
- Crash Detection & Accident Reconstruction
- Geo-fences
- Motion Detection
- Scheduled Timing Report
- OTA Control
Specifications:
| Operating Band | LTE Cat 1 bis FDD: B2/B4/B5/B12/B13/B66/B71 |
| Data Transmission |
LTE-FDD: Max 10Mbps (DL)/Max 5Mbps (UL) |
| GNSS Type | u-blox All-in-One GNSS receiver |
| Sensitivity |
Cold start: -148 dBm Hot start: -163 dBm Tracking: -165 dBm |
| Position Accuracy (CEP) | Autonomous: <2.0m |
| TTFF (Open Sky) |
Cold start: 24s average Hot start: 1s average |
| Dimensions | 50(L) x 49(W) x 24(H) mm 1.97(L) x 1.93(W) x 0.94(H) inch |
| Weight | 51g |
| Backup Battery | Li-Polymer, 60 mAh |
| Operating Voltage | 8 - 32V DC |
| Transmitting Protocol | TCP, UDP, SMS |
| Scheduled Timing Report | Report position and status based on preset time intervals, distance, mileage or a combination of these settings |
| OBDII Port | For external power source |
| Geo-fences | Geo-fence alarm and parking alarm, support up to 20 internal geo- fence regions |
| Power On/Off Report | Report when the device is powered on and off |
| Driving Behavior Monitoring | Aggressive driving behavior detection, including harsh braking, acceleration, etc. |
| Crash Detection | Accident data collection for reconstruction and analysis |
| Cellular Antenna | Internal Only |
| GNSS Antenna | Internal Only |
| LED Indicators | GNSS,CEL,PWR |
| Micro USB | Used for upgrading and debugging |
